| S5B PRO 5inch Rugged Data Terminal |
| Rugged |
IP67 ( Waterproof+ Dustproof + Dropproof) |
| OS |
Android 9.0 |
| Size |
5 inch |
| CPU |
MTK6765 Octa core 2.0 GHz |
| Memory |
2GB ( optional : 3GB/4GB/6GB) |
| Flash Rom |
16GB( optional : 32GB/64GB/128GB) |
| Touch LCD |
IPS 1280x720, Corning Gorilla Glass 3, Sunshine Visible, Glove touch support |
| Battery |
5000 mAh Lithium polymer battery |
| Dual Wifi |
802.11 a/ b/g/n ( 2.4G/5G Bands dual wifi) |
| Bluetooth |
Bluetooth 4.0 |
| GPS |
Support |
| 4G bands |
FDD-LTE: B1/B3/B5/B7/B20 or B2/B4/B7/B17 TDD-LTE: B38/B39/B40/B41 WCDMA: B1 CDMA2000: BC0 TD-SCDMA: B39 GSM/GPRS2000: 850/900/1800/1900 |
| Camera |
Rear 13mp only |
| Interface |
type C USB charging |
| Sim + PSAM |
Dual Sim + Dual PSAM |
| Micro SD |
64G max. |
| 2D Built in |
Optional : 1D and 2D Barcode |
| NFC |
NFC( 13.56Mhz) |
| LF RFID |
Optional : LF 125K |
| Working temperature |
-10 to 50 degree C |
| Charging cradle |
Optional |
| Net weight |
229g(including battery) |
| Dimension |
152.5 mm x 76 mm x 17 mm |
| 2D SDK |
Support |
| Hand strap |
Support |
| ESD |
Support |
| Industrial grade, thin body, and light weight, Very Intelligent decoding |
|
|
|
|
|
 |
| TP8000D 8'' IP68 Android Tablet with optional 2D or UHF |
| Rugged |
IP68 ( Waterproof + Dustproof + Dropproof ) |
| CPU |
MTK6753 Octa-core 1.3GHz or MT6762 2.0GHz |
| OS |
Android 7.0 /Android 9.0 |
| 4G bands |
GSM: B2/B3/B5/B8 TD-SCDMA: B34/B39
WCDMA: B1/B2/B5/B8 CDMA20001x/EVDO: BCO
FDD-LTE: B1/B3/B7 Europe Asia
FDD-LTE : B2/B4/B5/B8/B7/B12/B17 USA
TDD-LTE: B38/B39/B40/B41 |
| SIM |
Just one |
| RAM |
3GB( optional : 4GB) |
| ROM |
32GB( optional : 64GB) |
| TF card |
Support |
| Touch LCD |
8 inch , Corning Gorilla Glass III touch screen, HD1280x720
Optional : wet finger and passive pen signature electromagnetic display |
| Cameras |
Front 5mp + Rear 13mp |
| Wifi |
IEEE802.11 a/b/g/n, support 2.4/5.0 GHz,dual bands WIFI |
| Bluetooth |
V5.0 |
| GPS |
GPS / GLONASS |
| 2D ( Optional) |
1D & 2D as QR Code, PDF417, Data Matrix, etc. |
| NFC |
Support(MT6605) |
| UHF ( Optional) |
Reading distance : discuss |
| Sensors |
Light sensor, Sensing sensor, Gyro sensor, Compass sensor |
| Battery |
9500mAh |
| OTG |
Support |
| Dimension |
226.4(L)*142(W)*18(H)mm |
| Net weight |
About 800g (include battery) |
| Leather belt |
Support |
| Safety |
CE/RoHs/FCC compliance |
| Advantage |
Very Rugged and beautifull Slim design |
|
|
|
|
|
|
|
 |
| TP8014 8'' Rugged Tablet with Fingerprint & NFC |
| Rugged |
IP68 ( Waterproof + Dustproof + Dropproof ) |
| CPU |
MT6765 octa-core 2.3GHz+ |
| OS |
Android 9.0 |
| RAM |
3GB ( optional : 4GB) |
| ROM |
32GB ( optional : 64GB) |
| Touch LCD |
8 inch , Rugged touch screen, FHD1920*1200px |
| Wifi |
IEEE802.11 a/b/g/n, support 2.4/5.0 GHz,dual bands WIFI |
| Bluetooth |
V5.0 |
| GPS |
GPS / GLONASS /GALILEO |
| 4G bands |
GSM: B2/B3/B5/B8
WCDMA: B1/B8(900/2100mhz)
FDD-LTE: B1/B3/B7/B20 Europe Asia or
FDD-LTE : B2/B4/B5/B7/B17 USA |
| Fingerprint |
Support / Unlock |
| NFC |
Support |
| Camera |
Front 5mp + Rear 13mp |
| SIM |
Just one |
| TF card |
Support |
| Interface |
Micro USB X 1 |
| Sensors |
Support : Light sensor, Gravity acceleration sensor |
| Optional : Gyroscope sensor, |
| Battery |
6000mAh , fixed |
| Dimension |
216.8(L)*128.1(W)*8mm(H) |
| Net weight |
About 480g (include battery), not include the back leather belt |
| Safety |
CE/RoHs/FCC compliance |
| Advantage |
High spec. but Slim design |
|
|
|
|
|
 |
| TP10033 10.1'' IP68 Slim Tablet with 2D/NFC/Fingerprint |
| Rugged |
IP68 ( Waterproof + Dustproof + Dropproof ) |
| CPU |
Intel Atom X5-Z8350 4G Quad-core 1.84GHZ |
| OS |
Windows 10 Home/Pro/IOT or (Android 9.0/CPU change to MT Octa core MT6762) |
| RAM |
2GB ( oponal : 4GB) |
| ROM |
32GB ( optional : 64GB) |
| Touch LCD |
10.1 inch , Rugged touch screen, HD 1280x800IPS
(Optional: FHD1920*1200px) |
| Wifi |
IEEE802.11 a/b/g/n, support 2.4/5.0 GHz,dual bands WIFI |
| Bluetooth |
V5.0 for Android OS |
| GPS |
GPS + GLONASS |
| 4G bands |
GSM:900+1800 WCDMA:900+2100;(UL:5.76Mbps,DL:21Mbps） or GSM:850+1900 WCDMA:850+1900； FDD-LTE: B1/B3/B7/B20 or FDD-LTE :B2/B4/B5/B7/B17 |
| Fingerprint |
Optional (FBI approved or TCS1 commercial fingerprint ) |
| Barcode |
Optional : 1D & 2D Barcode as QR Code, PDF417, Data Matrix |
| NFC |
13.56mhz( Optional ) |
| Camera |
Front 2mp + Rear 5mp for Windows OS
Front 5mp + Rear 13mp for Android OS |
| SIM |
Just one |
| Micro SD |
Support |
| Interface |
Micro USB 2.0 X 1 |
| Sensors |
Gravity acceleration sensor, Light sensor,
Sensing distance |
| Battery |
9500mAh |
| Pogo pin |
One group 5pin |
| Stylus Pen |
Optional ( Active type) |
| Dimension |
285(L)*173(W)*14mm(H) |
| Net weight |
About 900g (include battery) |
| Safety |
CE/RoHs/FCC compliance |
| Car charger |
optional |
|
|
|
|
|
 |
| TP5503 5.5'' Rugged Smartphone with Fingerprint & NFC |
| Rugged |
IP68 ( Waterproof + Dustproof + Dropproof ) |
| CPU |
MT6761 Quad core / MT6762 Octa core |
| OS |
Android Android 9.0 |
| RAM |
3GB ( optional : 4GB ) |
| ROM |
32GB ( optional : 64GB ) |
| Touch LCD |
5.5 inch , Gorilla glass 3 touch screen, HD1440*720IPS |
| Wifi |
IEEE802.11 a/b/g/n/ac, support 2.4/5.0 GHz,dual WIFI |
| Bluetooth |
V4.0 |
| GPS |
GPS + AGPS + Glonass |
| 4G bands |
2G: GSM B2/B3/B5/B8
3G：WCDMA B1/B2/B5/B8
4G: FDD-LTE B1/B2/B3/B4/B5/B7/B8/B17 or B20 or B28A/B28B |
| Fingerprint |
Optional Support |
| NFC |
Optional Support |
| PTT |
Support |
| Sensors |
G-sensor, Three axis gyroscope sensor, Compass sensor, Distance sensor, Light sensor |
| Cameras |
5mp front+ 13mp & 0.3mp Rear |
| SIM |
Dual |
| Micro SD card |
Support |
| Interface |
Type C Micro USB X 1 |
| Battery |
5000mAh |
| Wireless charger |
Optional |
| Dimension |
156(L)*74.8(W)*14.5mm(H) mm |
| Net weight |
260g (include battery) |
| Safety |
CE/RoHs/FCC compliance |
| Advantages |
Suitable for worldwide traveling use |
|
|
|
|
|
 |
| TANK20 Rugged IP69 Data Terminal |
| Rugged |
IP69 ( Waterproof + Dustproof + Dropproof/2M ) |
| CPU |
MTK6739V/CW（64bit, Quad-core, 1.5Ghz） |
| OS |
Android 8.1 |
| RAM |
2GB |
| ROM |
16GB |
| Touch LCD |
5 inch , Corning Gorilla glass 3 touch screen, HD1280*720IPS |
| Wifi |
IEEE802.11 a/b/g/n, support 2.4/5.0 GHz,dual bands WIFI |
| Bluetooth |
V4.2 |
| GPS |
GPS or GLONASS+ AGPS |
| 4G bands |
GSM：850/900/1800/1900（B5/B8/B3/B2）
WCDMA：850/900/1900/2100（B5/B8/B2/B1）
FDD-LTE：B1/B3/B7/B8/B20
TDD-LTE：B38/B39/B40/B41
TD-SCDMA：B34/39 C2K：BCO" |
| 2D Barcode |
1D & 2D Barcode with 2D SDK |
| NFC |
Support (NXP PN548) |
| PTT |
Support |
| Camera |
Front 2mp + Rear 8mp |
| SIM |
Dual |
| Micro SD |
Support |
| Interface |
Type C Micro USB X 1 |
| Battery |
5000mAh |
| Quick charging |
Support, 5V/2A |
| Magnetic charging |
Optional |
| Dimension |
156.5(L)x77(W)x18(H) mm |
| Net weight |
288g (include battery) |
| Advantages |
Very rugged with IP69 Level |
|
|
|
|
|
 |
| TP10032 10.1'' Rugged Windows Tablet |
| Rugged |
IP67( Dropproof + Dustproof + Waterproof) |
| OS |
Windows 10 Home/ Windows 10 Pro/
Windows 10 IOT/ Linux |
| Size |
10.1 inch |
| CPU |
Intel Cherry Z8350 1.94GHz |
| Memory |
4GB |
| Flash Rom |
64GB |
| Touch LCD |
IPS 1920 x 1200 |
| Battery |
12000mAH ( removeable) |
| Wifi |
802.11 a/b/g/n （2.4Ghz + 5Ghz) |
| Bluetooth |
Bluetooth 4.0 |
| GPS |
Support |
| 4G FDD LTE |
Optional |
| Camera |
Front 2mp+ Rear 5mp |
| Interface |
PCAT(type A) USB2.0 x 2 +PCAT type A USB3.0 x 1 + Micro USB x1 + RS232x1 +Lan( RJ45) x 1 + Micro HDMI x1 |
| 2D Barcode (optional) |
1D and 2D Barcode |
| NFC(optional) |
NFC( 13.56Mhz) |
| Charging cradle |
Optional |
| Dimension |
280*184*265mm |
| Net weight |
1.08kg |
|
|
|
|
|
 |
| TP8000Pro(MT6762 Version) 8'' IP68 Slim Android Tablet |
| Rugged |
IP68 ( Waterproof + Dustproof + Dropproof/1.5m ) |
| CPU |
MTK6762 Octa-core 2GHz |
| OS |
Android 9.0 / ( optional : Android 10 ) |
| 4G bands |
GSM: B2/B3/B5/B8 TD-SCDMA: B34/B39
WCDMA: B1/B2/B5/B8 CDMA20001x/EVDO: BCO
FDD-LTE: B1/B/2/B3/B4/B5/B7/B8/B20/B12/B17/B28A/B
TDD-LTE: B38/B39/B40/B41 |
| Memory |
4GB Ram + 64GB Rom |
| Touch LCD |
8 inch , Gorilla Glass 3 touch screen,
HD1280x800px,( Optional : FHD1920x1080)
Brightness : 350cd/m2 ( optional : 450cd/m2) |
| Wifi |
IEEE802.11 a/b/g/n, support 2.4/5.0 GHz,dual bands WIFI |
| Bluetooth |
V5.0 |
| GPS |
GPS / GLONASS |
| NFC |
Support |
| Sensors |
Light sensor, Sensing sensor, Gyro sensor, Compass sensor |
| Cameras |
Front 5mp + Rear 13mp |
| SIM |
Just One |
| Micro SD card |
Support |
| Interface |
Micro USB x 1 & OTG |
| Battery |
3.7V/8500mAh Lithium Polymer |
| Working temperature |
-20 to 60 degree C |
| and leather belt |
Support |
| Stylus Pen |
Optional |
| Dimension |
226.4(L)*142(W)*18(H)mm |
| Net weight |
About 650g (include battery) |
| Safety |
CE/RoHs/FCC compliance |
| Advantage |
Very Rugged , Waterproof, but Slim |
|
|
|
|
|
 |
| TP10021 10.1'' Reliable Tablet |
| OS |
ANDROID 10.0 |
| Screen |
10.1 inches IPS , 1280*800 |
| CPU |
SC9863A CortexTM A55 MP8 ,1.6Ghz,Octa core |
| Memory |
4GB Ram + 64GB Rom |
| Battery |
3.7V/12000mAh |
| WiFi |
IEEE 802.11b/g/n |
| Bluetooth |
V4.2 |
| Camera |
Front 0.3MP+ Rear 2MP
( Optional : Front 2MP+ Rear 5MP) |
| G-Sensor |
4-Directions gravity sensing |
| GPS |
Yes |
| 4G LTE |
B1/B3/B7/B20 or B2/B4/B7/B28 or others |
| Charging |
USB charge |
| I/O ports |
1 x Micro USB |
| |
1 x TF Card Slot |
| |
2 x SIM Card Slot |
| |
1 x Earphone Jack |
| Power adapter |
5V,2A |
| Case material |
Metal |
| Case color |
Shell color Black, Blue, Gold, Rose Gold |
| Working Temp. |
(-15) to (+65) degree C |
| Net weight |
About 0.7kgs |
|
|
|
|
|
 |
| TP8015 8'' Rugged TabletPOS |
| Rugged level |
IP68 |
| OS |
Android 7.0 |
| CPU |
MSM 8909 Quad- core 1.3GHz
( optional : MSM 8953 Octa-core 1.5GHz / or 2.2GHz ) |
| RAM+ROM |
MSM8909:2GB+16GB;
Optional : MSM8953: 3GB+ 32GB/4GB+64GB |
| Touch LCD |
8.0'' HD（1280*800）
(optional : FHD（1200*1920）
Gorilla 3 /Glove touch |
| 4G Bands |
MSM 8909: GSM/GPRS/EDGE: B2/B3/B5/B8
WCDMA:B1CDMA1X, EVDO:BC0
FDD:B1/B3, TDD:B39/B40/B41 |
MSM 8953:GSM B2/B3/B5/B8
TD-SCDMA: B34/B39
WCDMA: B1/B2/B5/B8
CDMA20001x/EVDO: BCO
FDD: B1//B3 , TDD: B38/B39/B40/B41 |
| Bluetooth |
4.0+LE |
| Wifi |
support 2.4/5.0 GHz,dual band WIFI |
| NFC |
support(MT6605) |
| USB data transfer |
support |
| Storage card |
32GB for Quad core CPU / 128GB for Octa core CPU |
| OTG |
support |
| Sensor |
G-sensor(accelerometer)+ Gyro sensor+ Compass sensor |
| Fingerprint |
optional |
| Face recognition |
optional |
| Psam card |
optional ( 2) |
| RFID |
optional |
| 2D Barcode |
Optional |
| Chip IC card reader |
Optional : Contact type
- meet ISO 7816 Chip IC Card with SDK |
| GPS |
GPS / GLONASS/BDS |
| Camera |
2mp front + 8mp rear
( optional : 5mp front+ 13mp rear for Octa core CPU) |
| Battery |
8500mAh Internal |
| Net weight |
~800g |
| Dimension |
235*140*20mm |
|
|
|
|
|
 |
| TP6410 6'' Smartphone with FACE ID and Fingerprint |
| CPU |
MediaTek ,Helio P60,Octa Core,2.3GHz |
| OS |
Android Android 10 |
| RAM |
4GB ( optional : 6GB ) |
| ROM |
64GB ( optional : 128GB ) |
| Touch LCD |
6.41 inch , Corning Gorilla glass touch screen, FHD+ IPS (1080*2310) |
| Wifi + Bluetooth |
Support |
| GPS |
Support |
| 4G LTE |
Support |
| Fingerprint |
Support |
| FACE ID |
Support |
| Sensors |
G-sensor, , Distance sensor, Light sensor |
| Cameras |
20mp front+ 16.0 MP AF +2MP+2MP+2MP Rear |
| SIM |
Dual |
| Micro SD card |
Support |
| Interface |
Type C USB X 1 |
| Battery |
4000mAh ( quick charging) |
| Dimension |
157x76x8.8mm |
| Net weight |
170g (include battery) |
| Advantages |
Rugged Touch LCD Glass and Face ID + Fingerprint |
|
|
|
|
|
 |
| TP8053 8'' Hardness Touch Screen Tablet |
| CPU |
Spreadtrum T618 2.0GHz Octa core |
| OS |
Android : 10 |
| 4G FDD LTE |
FDD : B1/3/7/20 or FDD : B2/4/7/17 |
| Memory |
4GB Ram + 64GB Rom |
| Touch LCD |
8 inch , HD1280x800, undershine can read |
| Wifi |
IEEE802.11 a/b/g/n, support 2.4/5.0 GHz,dual bands WIFI |
| Bluetooth |
V5.0 |
| GPS |
GPS / GLONASS |
| Sensors |
G-Sensor, optional : P-Sensor and L-Sensor |
| Cameras |
Front 2mp + Rear 5mp |
| SIM |
Just One |
| TF card Slot |
Support |
| Interface |
Type C charging |
| Battery |
5100mah |
| Dimension |
218 x 215 x 7.6mm |
| Safety |
CE/RoHs/FCC compliance |
|
|
|
|
|
 |
| TP8016 8inch Rugged Tablet- Android type |
| Rugged rate |
IP65( Dropproof + Waterproof+ Dustproof) |
| CPU |
MSM8953 Octa-core 2GHZ |
| OS |
Android 9.0 |
| LCD |
8" touchscreen ( 16:10 800X1280 IPS) |
| RAM and Rom |
4G Ram + 64GB Flash Rom |
| WiFi + Bluetooth |
802.11 a/b/g/n（2.4G/5G dual band wifi）
+ Bluetooth V4.0 |
| Camera |
Front 5.0MP+ Rear 13 MP |
| Battery |
6000mAh /3.7V |
| Sensor |
G-Sensor+ L-Sensor+Compass +Gyro |
| 4G FDD |
Support |
| GPS |
GPS+BeIDou+AGPS |
| TF Card slot |
x1 max. 128G |
| SIM |
Just one |
| USB connector |
USB 2.0*1 、Type C charging x 1 |
| HDMIconnector |
MINI HDMI x1 |
| Barcode (optional) |
1D Barcode or 2D Barcode built in. |
| NFC( optional) |
ISO/IEC 14443A/1443B/15693 |
| Back hand strap |
Support |
| Charging cradle |
Optional |
| Net weight |
690g ( including battery) |
| Dimension |
227.5*150*22 mm |
| Safety |
CE Meet |
|
|
|
|
|
 |
| TP10032 10.1'' Rugged Android Tablet |
| Rugged |
IP67( Dropproof+ Dustproof + Waterproof) |
| OS |
Android 9.0 |
| Size |
10.1 inch |
| CPU |
RK3399 |
| Memory |
4GB |
| Flash Rom |
64GB |
| Touch LCD |
IPS 1920 x 1200 |
| Battery |
12000mAH ( removeable) |
| Wifi |
802.11 a/b/g/n （2.4Ghz+5Ghz) |
| Bluetooth |
Bluetooth 4.2 |
| GPS |
Support |
| 4G FDD LTE |
Optional |
| Camera |
Front 2mp+ Rear 5mp |
| Interface |
PCAT USB(2.0) type A x 2 + PCAT USB(3.0) Type A x 1 + Micro USB x1 + RS232x1 +Lan( RJ45) x 1 + Micro HDMI x1 |
| 2D Barcode (optional) |
1D and 2D Barcode |
| NFC(optional) |
ISO14443A/B + ISO15693 |
| Charging cradle |
Optional |
| Car charger |
Optional |
| Hand strap |
Support |
| Shoulder strap |
Optional |
| Dimension |
280*184*26.5mm |
| Net weight |
1.08kg |
|
|
|
|
|
 |
| TP8018 8'' Rugged Tablet with optional Fingerprint & NFC& 2D |
| OS |
Android 10 |
| CPU |
MT6765， 2.4GMHz Octa-core |
| RAM/ROM |
4GB+64GB EMMC |
| Camera |
5MP front +13MP rear |
| LCD Dispaiy |
800*1280 |
| SD /SIM card |
Micro-SD card reader; maximum 128GB; three-select two |
| Dimetions |
253*152*18mm |
| NFC |
Support ISO/IEC14443A, 14443B, 15693, etc.(optional) |
| 2D Barcode |
1D & 2D Barcode - optional |
| Fingerprint |
TCS1(with FBI ) - optional |
| Battery |
7500 mAh/8000mah optional |
| Wifi |
2.4G+ 5G dual band |
| Bluetooth |
V5.0 |
| GPS |
Support |
| 4G FDD LTE |
Support, As customer want |
| Recharge |
Support TYPE C fast charge |
| Others |
Magnetic compass, gyroscope |
| Rugged Level |
IP67 ( Dropproof 1.5m+ waterproof + dustproof) |
| Net weight |
about 800g |
| CE |
Meet |
| Back hand belt |
Optional |
| Warranty |
One year |
|
|
|
|
|
 |
| TP8000D 8'' IP68 Windows Tablet |
| Rugged |
IP68 ( Waterproof + Dustproof + Dropproof ) |
| CPU |
Intel Z8350 Quad core 1.84Ghz |
| OS |
Windows 10 Home/Windows 10 Pro/Windows 10 IOT |
| 4G bands |
GSM: B2/B3/B5/B8 TD-SCDMA: B34/B39
WCDMA: B1/B2/B5/B8 CDMA20001x/EVDO: BCO
FDD-LTE: B1/B3/B7 or FDD-LTE : B2/B4/B5/B8/B7/B12/B17
TDD-LTE: B38/B39/B40/B41 |
| RAM |
2GB ( optional : 4GB) |
| ROM |
32GB ( optional : 64GB) |
| Touch LCD |
8 inch , Gorilla Glass 3 touch screen, HD1280x800px ( optional: FHD1920x1200)
Optional : wet finger and passive pen signature electromagnetic display
|
| Wifi |
IEEE802.11 a/b/g/n, support 2.4/5.0 GHz,dual bands WIFI |
| Bluetooth |
V4.0 |
| GPS |
GPS / GLONASS / BDS triple |
2D Barcode
(optional) |
1D & 2D as QR Code, PDF417, Data Matrix, etc.
Support 2D Barcode SDK development kit |
| NFC |
Support |
| UHF (optional) |
Discuss |
| Sensors |
Light sensor, Sensing sensor, Gyro sensor, Compass sensor |
| Cameras |
Front 2mp + Rear 5mp |
| SIM |
Just One |
| Micro SD card |
Support |
| Interface |
Micro USB x 1 & OTG |
| Battery |
9500mAh |
| Pogo pin |
One group 6 pin |
| Hand leather belt |
Support |
| Stylus Pen |
Optional ( Active capacitive pen) |
| Dimension |
226.4(L)*142(W)*18(H)mm |
| Net weight |
About 800g (include battery) |
| Safety |
CE/RoHs/FCC compliance |
| Advantage |
Very Rugged , Waterproof, but Slim & high class design |
|
|
|
|
|
|
|
|
|
